Powerstone supplies high-efficiency 570-595W bifacial solar panels and smart 100Ah–320Ah LiFePO4 batteries with built-in fire protection, 6,000–8,000+ cycles, and long-term warranty support.
High-performance wall and stand-mounted LiFePO4 battery banks (100Ah–320Ah) designed for 6,000 to 8,000+ deep cycles, universal hybrid inverter communication, and multi-layer thermal safety.
Internal automated fire suppression device detects and neutralizes cell hotspots instantly before propagation.
Grade-A brand new LiFePO4 cells offering 10+ years design life and a 5-year comprehensive manufacturer warranty.
CAN & RS485 auto-matching with 10+ leading inverters: Growatt, Deye, MUST, INVT, Megarevo, Luxpower, Sofar, and more.
Real-time HD color touchscreen showing individual cell voltages, SOC%, and temperature, plus wireless app monitoring.
Available Model Lineup
5.12 kWh Total Energy (4.6 kWh Usable)
Ideal for residential solar systems. Features an integrated color touch screen, WiFi monitoring, and compact wall or floor footprint.
16.38 kWh Total Energy (14.7 kWh Usable)
Massive energy storage for luxury homes, estates, commercial sites, and demanding backup. Includes heavy-duty transport castors and floor stand.
2.56 kWh Total Energy (2.3 kWh Usable)
Compact 24V energy storage for smaller off-grid cabins, telecom shelters, or mobile power. Shipped with complete heavy-duty double M8 cables and hardware.
Every Powerstone lithium battery pack comes equipped with an internal automated fire protection mechanism. In testing under leading safety protocols, even if internal battery temperature reaches 100°C within 10 minutes, the external enclosure remains at safe room temperature, stopping thermal runaway in its tracks.
Internal Suppression
Built-in device
Thermal Limit
100°C containment
Safety Standards
UN38.3, MSDS, CE
Smart BMS CAN/RS485 auto-detects and connects with:
Full Technical Specifications
| Specification | SK-25.6V 100Ah | SK-51.2V 100Ah | SK-51.2V 320Ah |
|---|---|---|---|
| Battery Chemistry | LiFePO4 (Grade A) | LiFePO4 (Grade A) | LiFePO4 (Grade A) |
| Total Energy | 2,560 Wh (2.56 kWh) | 5,120 Wh (5.12 kWh) | 16,384 Wh (16.38 kWh) |
| Usable Energy (90% DoD) | 2,304 Wh | 4,608 Wh | 14,746 Wh |
| Voltage Window | 22.4V – 29.2V | 44.8V – 58.4V | 44.8V – 58.4V |
| Fast / Float Charge Voltage | 28.8V / 28.0V | 57.6V / 56.0V | 57.6V / 56.0V |
| Low DC Cut-off Voltage | 24.0V | 48.0V | 48.0V |
| Max Continuous Discharge | 100A | 100A | 200A |
| Max Pulse Discharge (1s) | 150A | 150A | 300A |
| Max Continuous Charge | 50A | 50A | 150A |
| Parallel Scalability | — | 1–15 units (76.8 kWh) | 1–15 units (245.7 kWh) |
| Communication Ports | RS485 | CAN, RS485 | CAN, RS485 |
| Cycle Life (@ 25°C, 0.2C, 90% DoD) | >6,000 Cycles | >6,000 Cycles | >8,000 Cycles |
| Fire Protection Device | Built inside | Built inside | Built inside |
| Terminals | Double M8 | Double M8 | Double M8 |
| Installation Style | Wall / Stand Mounted | Wall / Stand Mounted | Floor Stand + Castors |
| Product Dimensions (L×W×H) | 520 × 390 × 178 mm | 640 × 390 × 178 mm | 850 × 560 × 178 mm |
| Weight (Net / Gross) | 29.9 kg / 30.4 kg | 46.0 kg / 50.3 kg | 123 kg / 139.9 kg |
| Safety Standard & Warranty | UN38.3, MSDS, CE • 5-Year Factory Warranty • 10+ Years Design Life | ||
Choose the bifacial panel, inverter, battery, and support package that fits your property, budget, and timeline. Each product path keeps specs, warranty coverage, and handoff details clear.
Powerstone product supply
High-output N series bifacial modules for homes, businesses, and clean-energy projects that need dependable daily generation.
Bifacial 144 half-cell modules for larger rooftops, commercial arrays, and buyers who need stronger module performance.
Hybrid inverters, batteries, and accessories matched to Powerstone N series panel classes.
Product support for panel records, warranty questions, serial verification, and long-term performance checks.
Datasheet details
Download the Powerstone N series M10 TOPCon bifacial module datasheet for output ratings, electrical parameters, mechanical dimensions, warranty notes, and packaging details.
Download Datasheet570-595W
Datasheet power classes for the CETC-570-595T (GDF) /144 module range.
23.0%
Peak listed module efficiency under standard test conditions.
0~+5W
Positive output tolerance listed for the N series module range.
144
M10 TOPCon bifacial module structure with 144 half cells.
Before you order
Compare bifacial module output, quantity, roof or land limits, and future expansion needs.
Review module efficiency, output expectations, and suitable inverter or battery pairings before install day.
Review 15-year product warranty coverage and 30-year linear power warranty details for eligible modules.
Confirm panel records, delivery timing, installation handoff, and verification support before ordering.
Ready for procurement
Request a no-obligation quote for Powerstone 570W-595W bifacial panels with 23.0% maximum efficiency, warranty-backed performance, and matching equipment.
